Markerless IR Rapid Scan Handheld 3D Scanner for Feature-Rich Workpieces
USD 12000,00 – 20000,00
/ Piece
Le prix varie selon la quantité et les spécifications
| Qté min. | 1 Piece |
| Catégorie | Instruments & Meters |
22
Ans
98%
Taux de réponse
24h
Délai de réponse
Plus de ce fournisseur
Description du produit
Aucune description disponible. Veuillez envoyer une demande pour plus d'informations.
Spécifications techniques
| Model NO. | FreeScan Combo / FreeScan Combo+ |
| After-sales Service | Online Support |
| Warranty | 1 Year |
| Style | Portable |
| Interface Type | USB |
| Network Scanning | Support Network |
| Certification | ISO, CE, FCC, RoHS, Weee, Kc, FDA, Ukca, IP50, Tisax |
| High-Speed Scanning | 50 Laser Lines (Combo+) or 26 Laser Lines (Combo) |
| Deep Pockets | 1 Single Line |
| Accuracy | 0.02 mm |
| Volumetric Accuracy | 0.02 + 0.033 mm/M |
| Scan Speed | up to 3, 600, 000 Points/S |
| Detailed Scan | 7 Parallel Laser Lines |
| No-Markers Scan | Infrared Mode |
| Max. Fov | 520 × 510 mm / 600 × 600 mm |
| Point Distance | 0.05 ~ 10 mm / 0.1 ~ 3 mm |
| Weight | 620 G |
| Lead Time | 10-15 Days |
| Accuracy Certification | Vdi/VDE 2634 Part 3 & ISO 10360 Certified |
| Transport Package | Carton Box |
| Specification | 193 × 63 × 53 mm |
| Trademark | SHINING 3D |
| Origin | Hangzhou, China |
| HS Code | 9031499000 |
