Manufacturer & Trading Company
High-Performance Precision Punch Press Machine for Metal Fabrication and Stamping
USD 6200,00 – 6600,00
/ piece
Le prix varie selon la quantité et les spécifications
| Qté min. | 1 piece |
| Catégorie | Machinery |
9
Ans
98%
Taux de réponse
24h
Délai de réponse
Plus de ce fournisseur
Description du produit
Aucune description disponible. Veuillez envoyer une demande pour plus d'informations.
Spécifications techniques
| Model NO. | BLM Series |
| After-sales Service | Remote Guidance |
| Warranty | One-Year Warranty |
| Type | General Punching Machine |
| Punch Shape | Open Punch |
| Slider Movement | Single Action |
| Slider Drive Mechanism | Crank Press |
| Automatic Grade | Automatic |
| Power Source | Electric |
| Precision | High Precision |
| Certification | GS, CE, RoHS, ISO 9001 |
| Condition | New |
| Product Name | Precision Punch Press |
| Keywords | Punching Machine |
| Model | Blm-110/Blm-200/Blm-110/Blm-200 |
| Capacity (Ton) | 110/200 |
| Rate Tonnage Point (mm) | 5/3 6/3 |
| Stroke (mm) | 180/110 180/130 250/150 280/170 |
| Stroke Per Minute (S.P.M) | 35-65/500-100 30-55/40-85 20-50/35-70 20-40/30-60 |
| Die Height (mm) | 400/350 450/400 500/450 550/450 |
| Slide Adjustment (mm) | 100/120 |
| Main Motor (Kw.P) | 11*4/15*4/18.5*4/30*4 |
| Air Pressure (Kg/Cm2) | 6 |
| Transport Package | Standard Packaging or Customized |
| Specification | Standard Specifications or Customized |
| Trademark | JBLDY |
| Origin | Shandong, China |
| HS Code | 8428399000 |
